Universal 325 Product Specifications

The Universal Model 325 (U325 Series) is a 2-inch thick, non-insulated steel garage door built for dependable residential performance and a classic raised-panel design. This model features a carriage bead board definition pattern and a rotary-embossed woodgrain texture that adds depth and helps the door maintain a clean appearance over time. Universal 325 is a strong match for homeowners in Richmond, CA who want a durable steel door with upgrade paths for insulation, reinforced hardware, and finish customization.

Product Overview of Universal 325

Universal Model 325 (U325 Series)

25 Gauge, 2-Inch Thick Non-Insulated Steel Door

2-inch thick steel sections – Built for stable daily operation and long-term performance.
Woodgrain embossed steel – Textured surface supports a refined exterior design.
RITS reinforced integral truss system – Added strength built into the panel structure.
Bead board raised-panel definition – Traditional styling with carriage-inspired character.
Upgrade-ready build – Supports insulation, enhanced hardware, and finish customization.

Features & Benefits

25-Gauge Galvanized Steel Sections

Built from hot dipped galvanized steel for durability and corrosion resistance.

2-Inch Thick Sectional Construction

Offered in 21″ and 18″ section heights for a solid, stable door build.

Carriage Bead Board Definition

Traditional definition raised panels are pressed in incremental heights for a crisp, dimensional appearance.

Tongue-and-Groove Metering Rails

Helps support a tighter fit between sections for improved weather performance.

RITS Reinforced Integral Truss System

Reinforcement is engineered into the section design for added strength.

Heavy-Duty Stiles and Reinforcement

Vertical stile members use 19-gauge galvanized I-beams; the bottom section is reinforced with aluminum angle to support a replaceable UV-protected bottom weather seal.

Residential-Ready Hardware Package

Hot-dipped galvanized wide-body end roller hinges and interior hinges paired with 2″ black nylon rollers for smooth rolling performance.

Specifications

Specification

Universal Model 325 (U325 Series)

Door type

Non-insulated steel sectional garage door

Steel gauge

25-gauge hot-dipped galvanized steel

Section thickness

2 inches

Section heights

21" and 18."

Finish

Pre-painted white; rotary embossed woodgrain texture

Panel style

Traditional definition raised panels; Carriage Bead Board definition (18" x 13 3/4")

Rail design

Tongue-and-groove metering rails with RITS reinforcement

Stiles

19-gauge galvanized I-beam center/end stiles; riveted and bonded with epoxy-based cement

Bottom reinforcement

Aluminum “L” angle; supports replaceable UV-protected bottom weather seal

Hinges

Hot-dipped galvanized 14/16-gauge wide-body end roller hinges; 14/16-gauge interior hinges

Rollers

2" black nylon rollers

Track/shaft components

Galvanized torsion tube; self-locking fasteners; pre-painted torsion springs

Optional lock

Inside slide lock (optional)

Widths

8', 9', 10', 12', 14', 15', 15'8", 16', 18.'

Heights

6'0" through 14'0" in 3" increments (additional heights available)

Warranty

Limited Lifetime Warranty

Options / Customization

Insulation upgrade: CFC-free polystyrene insulation with rigid high-impact vinyl back skin; R-factor 6.25 listed for the insulated configuration.
Color options: White, Sandstone, Brown (factory-primed/painted; post-painting required).
Hardware upgrades (H-1): Optional 16-gauge commercial hinges throughout, upgraded fixtures, 10-ball black poly rollers, lift handles, pre-painted spring, galvanized torsion tube, plus upgraded track options (.045 vertical track and .055 horizontal track).
