Universal 225 Product Specifications

Universal 225 is a residential steel sectional garage door built for reliable daily operation and long-term durability. This model uses 25-gauge hot-dipped galvanized steel with a true 2-inch section profile, delivering a solid door feel while keeping the design practical for many home styles. Its raised panel embossment and woodgrain texture add a refined appearance, while reinforced section engineering supports consistent performance through frequent cycles. Universal 225 is a strong match for replacements, remodels, and new builds in Richmond, CA, especially when you want a durable door with upgrade flexibility for insulation, windows, and decorative accents.

Product Overview of Universal 225

Universal 225

U225 Series – 25 Gauge, 2″ Thick, Non-Insulated Steel Door

True 25-gauge steel construction – Manufactured from hot dipped galvanized steel for dependable service life.
2″ thick sections (18″ or 21″ heights) – Solid section profile designed for stable operation.
Woodgrain texture + raised panel embossment – Adds depth and a classic style.
RITS reinforced integral truss system – Reinforced meeting rail design for added rigidity.
Upgrade-ready platform – Supports insulation, glass, decorative hardware, and enhanced hardware packs.

Features

Reinforced Section Design

Tongue-and-groove meeting rails are roll-formed into the panel and built around the RITS reinforcement system. This design supports a tighter section interface and improved rigidity during operation.

Durable Interior Support

Vertical stile members are formed from 19-gauge hot-dipped galvanized I-beams for center and end stiles, designed to encapsulate the pan. Stiles are riveted and bonded to the interior face using an epoxy-based cement.

Bottom Section Reinforcement + Weather Seal Support

Bottom sections are reinforced with an aluminum “L” angle bonded to the section to support a replaceable UV-protected bottom weather seal helping maintain a clean threshold seal and supporting long-term usability.

Hardware Built for Residential Performance

Hinges are hot-dipped galvanized, using wide-body end roller hinges and interior hinges in 14/16 gauge. Rollers are 2-inch black nylon, with optional white nylon available. Additional hardware options are available for upgraded packages.

Specifications

Specification

Details

Series

U225 Series

Door type

Residential steel sectional garage door

Steel gauge

25-gauge hot-dipped galvanized steel

Section thickness

2 inches

Section heights

18" and 21" section heights

Surface finish

Pre-painted with rotary embossed woodgrain texture

Panel embossment options

U225 SP: Traditional Definition 19 1/4" x 13 3/4"; U225 LP: Traditional Definition 42" x 13 3/4"

Standard sizes

Widths: 8', 9', 10', 12', 14', 15', 15'8", 16', 18'

Height range

6'0" through 14'0" in 3" increments (additional heights available)

Stiles

19-gauge hot-dipped galvanized I-beams (center and end stiles)

Bottom reinforcement

Aluminum “L” angle with replaceable UV-protected bottom weather seal support

Hinges

Hot-dipped galvanized hinges; 14/16 gauge wide-body end roller hinges and 14/16 gauge interior hinges

Rollers

2" black nylon rollers (optional white nylon)

Insulation option

CFC-free polystyrene with rigid high-impact vinyl backskin; R-factor 6.25

Factory colors

White / Almond / Sandstone / Brown

Options / Customization

Glass designs: Multiple design selections available to add daylight and visual detail.
Decorative hardware: Multiple design selections available for a more customized finish.
Insulation upgrade: Polystyrene insulation with vinyl backskin for improved comfort and operational sound reduction.
Optional hardware package: Includes 16-gauge commercial hinges throughout, upgraded fixtures, 10-ball black poly rollers, lift handles, pre-painted spring, galvanized torsion tube, and heavier track options (.045 vertical track and .055 horizontal track).
Finish planning note: Doors are factory-painted; post-painting is recommended for customized exterior color matching and enhanced wood-style effect.
